LED Work Lamp, 8x10 Series

LED Work Lamp, 8x10 Series
LED Work Lamp, 8x10 Series
LED Work Lamp, 8x10 Series
Request a Quote

Description
The 8x10 series LED work lamp is designed with a patented technology. It features a higher efficiency and saves more energy than an LED with a traditional TIR lens. The precision die cast aluminum base of the LED automotive light ensures an excellent heat dissipation and a longer service life. Euro, spot, and floor patterns are available in the LED work lamps for vehicles.

  • 8Q10
  • 8Q10-F
8Q10

    Specification:
    Operating Voltage: DC10~33V
    Operating Temperature: -40℃~ 80℃
    Light Source: 48×1~3W high efficiency LEDs
    Color Temperature: warm white: ~3000K; natural white: 4000~4500K; pure white: ~6000K
    Luminous Flux: ~7000lm
    Light Emitting Angle: H40°/V30°
    Current: 3.2Amps @ DC24V
    Power: 90W (max.)
    Lens: UV resistant PC lens
    Housing: Die-casting aluminum housing with surface sprayed
    Accessories: big stainless steel bracket bolts screws
    IP 67,CE Approved

    8Q10-F

      Part Name: 8×10 LED Work Lamp
      Part No.: 8Q10-F
      Specifications

      Operating Voltage: DC10~33V
      Operating Temperature: -40℃~ 80℃
      Light Source: 48×1~3W high efficiency LEDs
      Color Temperature: warm white:~3000K; natural white:4000~4500K; pure white:~6000K
      Luminous Flux: ~7000lm
      Light Emitting Angle: H40°/V30°
      Current: 3.2Amps @ DC24V
      Power: 90W (max.)
      Lens: UV resistant PC lens
      Housing: Die-casting aluminum housing with powder coated surface
      Accessories: big stainless steel bracket bolts screws
      IP 67
      CE approved

      Packing Info:
      Individual white box, 4pcs/ctn,
      N.W=14.2KG/CTN, G.W=15.2KG/CTN,
      CTN SIZE: 46×33×24CM;
