KLS25-220-530 Standing Seam Roofing Machine
Request a Quote
KLS25-220-530 standing seam roofing machine is capable of profiling 0.7-1.0mm thick aluminum roof panel and 0.5-0.8mm thick steel roof panel. This machine can roll form both straight and tapered profiles. Schneider PLC control system is optional for easy operation. Small footprint is convenient for use on site.
Samples
Profile Drawing
Profiles of other shapes and sizes are also customable.
| Model | KLS25-220-530 |
| Dimension | 1800*1200*1000mm |
| Motor Power | 1.5KW |
| Hydraulic Power | 0.75KW |
| Forming Steps | 6Steps |
| Forming Speed | 8-15m/min |
| Voltage | 380V/50HZ/3PH |
| Effective Width | 220-530mm |
| Material Width | 290-600mm |
| Height of Roofing | 25mm |
| Aluminum Thickness | 0.7-1.0mm |
| Steel Thickness | 0.5-0.8mm |
| Control System | PLC Control |
- Main forming machine for make straight and tapered roof
- 5 Tons Manual Uncoiler
- Auto Seamer
- Hand Seamer
- PLC computer controlling system with touch screen (Brand: Schneider)
- Hydraulic Forming Cutter
- Device for Making Tapered Standing Seam Roofing
- Run Out Table
- Operation Manual
