YC65-470 Snap Lock Roofing Machine
Request a Quote
YC65-470 snap lock roofing machine forms continuous roofing panels and eliminates the need for screw fixing, avoiding rust around the screws and shortening installation time. This roofing machine is capable of profiling 0.4-0.8mm thick materials with a maximum production speed of 30m/min.
Samples
Profile Drawing
| Model | YC65-470 |
| Dimension | 7000*1500*1500mm |
| Motor Power | 5.5kW |
| Hydraulic Power | 2.2kW |
| Forming Steps | 17steps |
| Forming Speed | 10-15m/min |
| Voltage | 380V/50HZ/3PH |
| Material Thickness | 0.4-0.8mm |
| Rib Height of Roofing | 65mm |
| Effective Cover Width | 470mm |
| Feeding Material Width | 600mm |
| Control System | PLC Control |
-
-
Cutter is made by Cr12 mold steel, with HRC58-60 heat treatment for high quality and long service life.
-
-
Roller is made by high quality 45# steel with CNC lathes. Hard chrome plating is optional for long service life. Body frame is made of 400# H bean by welding
-
-
PLC can be chosen from Schneider, Siemens, and Delta
-
-
Auto Seamer
- Main Machine
- 5 Tons Manual Uncoiler
- Hydraulic Forming Cutter (Material:Cr12Mov with heat treatment)
- Hydraulic System
- PLC Computer Controlling System with touch Screen ( Brand: Schneider )
- Manual Pre-cutter OR Hydraulic Pre-cutter
- Tools
- Hand Seamer
- Auto Seamer
- Operation Manual
