Oil Tank Truck
Heavy Duty Truck Manufacturer in China
Offer tractor unit, dump truck, cargo truck, concrete mixer truck, bulk cement truck, tanker truck, etc.
With the rapid development of the world economy, common transport vehicles fail to satisfy customers' special needs. In this case, more specially built or modified vehicles are used for customers' special applications. These special trucks can be used to transport materials with different properties and in different states, e.g.: liquid, gaseous and bulk materials, granules; livestock, poultry, fish and other animals; toxic, inflammable and explosive goods. Tanker trucks, fire trucks, aircraft tractors, charging cars, and compressed air cars are some of common special trucks.
| Euro III Oil Tank Truck (Kingkan) | |||
| Model | |||
| Driving type | 6x4 | 8x4 | |
| Emission standard | Euro 3 | ||
| Vehicle kerb mass (kg) | 8850 | 11400 | |
| Gross vehicle weight (kg) | 25000 | 31000 | |
| Maximum speed (km/h) | 80 | 80 | |
| Wheelbase (mm) | 4200 1400 | 1800 3600 1400 | |
| Driver’s cabin | Flat roof cab with one narrow sleeper | Flat roof cab with one sleeper | |
| Engine | Model | WeichaiWP10.340E32 | WeichaiWP10.380E32 |
| Horsepower (hp) | 340 | 380 | |
| Emission (L) | 9.72 | 9.72 | |
| Torque (Nm) | 1350 | 1460 | |
| Gearbox | FAST 12 gears | FAST 12 gears | |
| Front axle | 7.5T | 9.5T | |
| Drive axle | HY300H | HY300H | |
| Tyre | 11.00 R20 | 12.00 R20 | |
| Truck frame | Double truck frame | Double truck frame | |
| Fuel tank(L) | 400 | 400 | |
| Options | Driver’s cabin | High roof cab with twin sleeper | |
| Gearbox | FAST 10 gears | ||
| Drive axle | HY300M, HY320 | ||
| Tyre | 315/80R22.5 | ||
| Fuel tank | 350, 600 | ||
| *The right-hand drive truck model is optional. | |||
| The above parameters are only a reference. Please contact with us for specific configurations. | |||
| Euro IV Oil Tank Truck (Kingkan) | |||
| Model | |||
| Driving type | 6x4 | 8x4 | |
| Emission standard | Euro 4 | ||
| Vehicle kerb mass (kg) | 8850 | 11400 | |
| Gross vehicle weight (kg) | 25000 | 31000 | |
| Maximum speed (km/h) | 80 | 80 | |
| Wheelbase (mm) | 4200 1400 | 1800 3600 1400 | |
| Driver’s cabin | Flat roof cab with one narrow sleeper | Flat roof cab with one sleeper | |
| Engine | Model | SFHC9 350 | SFHC9 390 |
| Horsepower (hp) | 350 | 390 | |
| Emission (L) | 8.71 | 8.71 | |
| Torque (Nm) | 1500 | 1590 | |
| Gearbox | FAST 12 gears | FAST 12 gears | |
| Front axle | 7.5T | 9.5T | |
| Drive axle | HY300H | HY300H | |
| Tyre | 11.00 R20 | 12.00 R20 | |
| Truck frame(mm) | Double truck frame | Double truck frame | |
| Fuel tank(L) | 400 | 400 | |
| Options | Driver’s cabin | High roof cab with twin sleeper | High roof cab with twin sleeper |
| Gearbox | FAST 10 gears | FAST 10 gears | |
| Drive axle | HY300M, HY320 | HY300M, HY320 | |
| Tyre | 315/80R22.5 | 315/80R22.5 | |
| Fuel tank | 350, 600 | 350, 600 | |
| *The right-hand drive truck model is optional. | |||
| The above parameters are only a reference. Please contact with us for specific configurations. | |||
| Euro V Oil Tank Truck (Genlyon) | |||
| Model | |||
| Driving type | 6x4 | 8x4 | |
| Emission standard | Euro 5 | ||
| Vehicle kerb mass (kg) | 8850 | 11400 | |
| Gross vehicle weight (kg) | 25000 | 31000 | |
| Maximum speed (km/h) | 80 | 80 | |
| Wheelbase (mm) | 4200 1400 | 1800 3600 1400 | |
| Driver’s cabin | Flat roof cab with one narrow sleeper | Flat roof cab with one sleeper | |
| Engine | Model | SFHC9 350 | SFHC9 390 |
| Horsepower (hp) | 350 | 390 | |
| Emission (L) | 8.71 | 8.71 | |
| Torque (Nm) | 1500 | 1590 | |
| Gearbox | FAST 12 gears | FAST 12 gears | |
| Front axle | 7.5T | 9.5T | |
| Drive axle | HY300H | HY300H | |
| Tyre | 11.00 R20 | 12.00 R20 | |
| Truck frame(mm) | Double truck frame | Double truck frame | |
| Fuel tank(L) | 400 | 400 | |
| Options | Driver’s cabin | High roof cab with twin sleeper | |
| Gearbox | FAST 10 gears | ||
| Drive axle | HY300M, HY320 | ||
| Tyre | 315/80R22.5 | ||
| Fuel tank (L) | 350, 600 | ||
| *The right-hand drive truck model is optional. | |||
| The above parameters are only a reference. Please contact with us for specific configurations. | |||
As a special truck manufacturer in China with decades of experience, SAIC HONGYAN Automotive Co.,Ltd is able to produce various kinds of special heavy duty trucks to suit customers' specific needs. Our typical products include concrete mixer trucks, bulk concrete trucks and tanker trucks. These products are widely used in the construction, chemical, transportation, energy, and other industries.
Apart from special trucks, we also manufacture tractor unit, dump trucks and cargo trucks. Known for their reliable performance, low fuel consumption and high durability, our products are sought after by customers in Africa, Southeast Asia, Central Asia, the Middle East, and South America.
No matter what kind of heavy duty vehicles you need, we will do our best to provide you the exact products you need, with considerate service.
