Bulk Powder Tank Truck
Heavy Duty Truck Manufacturer in China
Offer tractor unit, dump truck, cargo truck, concrete mixer truck, bulk cement truck, tanker truck, etc.
With the rapid development of the world economy, common transport vehicles fail to satisfy customers' special needs. In this case, more specially built or modified vehicles are used for customers' special applications. These special trucks can be used to transport materials with different properties and in different states, e.g.: liquid, gaseous and bulk materials, granules; livestock, poultry, fish and other animals; toxic, inflammable and explosive goods. Tanker trucks, fire trucks, aircraft tractors, charging cars, and compressed air cars are some of common special trucks.
Technical Parameters| Model | |
| Driving Type | 8×4 |
| Gross Vehicle Weight (kg) | 31000 |
| Kerb Mass (kg) | 18220 |
| Cab | High roof with double sleepers |
| Outside Dimension (L×W×H) (mm) | 11894×2500×3950 |
| Max. Speed (km/h) | 90 |
| Wheelbase (mm) | 1800 4600 1350 |
| Tank Volume | 41m³, 43m³ |
| Engine | Cursor 9-340hp, cursor 9-380hp |
| Displacement (L) | 8.71 |
| Combustion Type/Injection | 4 valves, electronic controlled common rail, turbocharging intercooler |
| Gearbox | 12JS160T |
| Rear Axle | Hub reduction rear axle casting housing/ratio 4.8 |
| Frame | High performance steel 865×317×(8 8) |
| Brake System | S-CAM actuated drum brake F/R |
| Dual line air brake system | |
| Suspension | F/R semi-elliptical suspension |
| Steering | ZF hydraulic power steering with variable ratio |
| Clutch | Φ430 diaphragm clutch |
| Fuel Tank | 400L (aluminum) |
| Tire | 12.00R20 |
| Emission STD | China III, Euro III |
As a special truck manufacturer in China with decades of experience, SAIC HONGYAN Automotive Co.,Ltd is able to produce various kinds of special heavy duty trucks to suit customers' specific needs. Our typical products include concrete mixer trucks, bulk concrete trucks and tanker trucks. These products are widely used in the construction, chemical, transportation, energy, and other industries.
Apart from special trucks, we also manufacture tractor unit, dump trucks and cargo trucks. Known for their reliable performance, low fuel consumption and high durability, our products are sought after by customers in Africa, Southeast Asia, Central Asia, the Middle East, and South America.
No matter what kind of heavy duty vehicles you need, we will do our best to provide you the exact products you need, with considerate service.
