Automatic Loading Conveying Equipment Manufacturer

Automatic Loading Conveying Equipment

Request a Quote

View All: http://wallpanellines.com/4-5-4-automatic-loading-conveying-equipment.html

Recommended application

Automatic loading conveying equipment is the combination of limit switch conveyor, roller conveyor and automatic gantry loading machine. It's applicable in matching works for the automatic loading or unloading of panel workpieces, such as panel furniture, door boards, cupboard side panels, calcium silicate boards, magnesium oxide boards and fiber cement panels.

Technical parameters

Working width	600-1300mm
Working thickness	3-50mm
Working pressure	0.4-0.6Mpa
Total weight	2500kg
Working length	1200-2500mm
Conveyor speed	3-5 units/min
Total power	10.6kw
Machine size	8200L×5500W×4200H mm

Features of automatic loading conveying equipment

The control system adopts automatic computer control. Combining touch screen, we can control fault display, operating speed and overturning speed and adjust parameters directly on the interface. The working state can also be displayed.
Vacuum suction cups are supplied by Schmalz and shows more stable performance.
Japanese Yaskawa motor and servo system are adopted, which can work reliably.

Index
panel conveyor, insulated wall panel, floor panel, furniture panel
