Backhoe Loader 630A
Request a Quote
View All: http://cn-changlin.com
Backhoe Loader 630A
Features of Backhoe Loader 630A:
1. Equipped with WD DETUZ engine
2. 4 forward & 4 reverse synchromesh mechanical shift transmission
3. Combined seal cylinder obtains high seal performance and more reliability
4. Improved loader and backhoe performance
5. CARRARO wet type rear axle with multi-disc brake& CARRARO front axle
6. New-type cab with more space, increases comfort and visibility
7. With 2 wheel driving or 4 wheel driving for option
| Model | 630A |
| Length×width×height(mm) | 7085×2313×3424 |
| Operating weight(Kg) | 7600 |
| Diesel engine type | WD DEUTZ WP4G 95E221 |
| Rated output(KW) | 70 |
| Transmission case type | CARRARO |
| Gear shift position | 4 Forward and 4 reverse gears |
| Max. traction force(KN) | 70 |
| Rated load(Kg) | 1700 |
| Rated load bucket capacity(m3) | 1.0 |
| Max. breakout force(KN) | 60 |
| Max. dump clearance(mm) | 2714 |
| Dump reach(mm) | 845 |
| Wheel base(mm) | 2155.5 |
| Total time of elevating, loading and unloading | 9.5 |
| Rated digging bucket capacity(m3) | 0.3 |
| Max. digging depth(mm) | 4405 |
| Max. digging radius(mm) | 5481 |
| Max. dumping height(mm) | 3737 |
| Max. digging force(KN) | 50 |
we are able to bring many products to the construction machinery and construction equipment market, including: wheel loaders, road rollers, motor graders, skid steer loaders, pavers, concrete truck mixers, Truck Mounted Crane , and we look forward to continuing this service for years to come.
