This 822mm Large Diameter Stringing Block possesses the dimension (outside diameter*root diameter*sheave width) of Φ822× Φ710× 110 (mm). Its maximum suitable conductor is LGJ630, which means that the aluminum of our conducting wire has the maximum cross section of 630 square millimeters.

The 10148 type product is designed with the assembled structure. It is really convenient to separate the conductor from middle sheave, thus helping reduce the weight during transportation. Dimension of the middle steel sheave is φ520×φ400×120 mm. Furthermore, we can also provide the rubber coated aluminum sheave, the rubber coated MC nylon sheave, as well as the reinforced nylon sheave coated by polyurethane.

Technical Parameters

Item Number Model Number of Sheave Rated Load (kN) Weight (kg) Features
10141 SHDN822 1 30 40 MC nylon sheave
10142 SHSQN822 3 60 118 Middle: cast steel sheave Conductor: MC nylon wheel
10143 SHWQN822 5 120 180
10146 SHQ822 7 120 285 Middle: cast steel sheave Conductor: MC nylon wheel
10148 SHJ822 9 150 445

Rubber lined MC nylon sheave for conductor can be customized.
