Chisel Carbide Bits

Request a Quote

View All: http://chinadragbit.com/carbide-tipped-rock-drill-bits-carbide-thread-bit-drag-bit.html

The Chisel Carbide Bits are produced using precision presses to ensure they are homogeneous in density, having excellent wear resistance and long service life. This makes them suitable for high-power rock drills to drill through complex and hard rock formations. The drag bit is widely used in various mining operations, including coal mining, iron-ore mining, gold mining, copper mining, and lead-zinc mining. The drag bit is also used in the construction of railways, highways, waterways, and much more.

Parameters:

Chisel carbide bits

Part NO.	Bit Diameter		Thread
Part NO.	mm	1n	Thread
SR1 34-25R 7°	34	1-3/8	R25, 7°
SR1 36-25R 7°	36	1-7/16	R25, 7°
SR1 38-25R 7°	38	1-1/2	R25, 7°
SR1 42-25R 30T	42	1-21/32	R25, T30
SR1 45-25R 30T	45	1-3/4	R2S, T30
SR1 48-32R 30T	48	1-7/8	R32, T30
SR1 51-32R 30T	51	2	R32, T30
SR1 55-32R 30T	55	2-5/32	R32, T30
SR1 57-32R 30T	57	2-1/4	R32, T30
SR1 60-32R 30T	60	2-3/8	R32, T30
SR1 64-321 38T	64	2-1/2	R32, R38
SR1 70-38R 40T	70	2-3/4	R38, T40
SR1 76-38R 40T	76	3	R38, T40
SR1 80-38R 40T	80	3-5/32	R38, T40
SR1 85-38T 45T	85	3-11/32	T38, T45
SR1 89-38T 45T	89	3-1/2	T38, T45
SR1 102-45T 51T	102	4	T45, T51
SR1 102-45T 51T	115	4-1/2	T45, T51
SR1 102-51T 73T	130	5-1/8	T51,T73
