GT-DJ200 Double Station Benchtop Dispensing Machine

GT-DJ200 Double Station Benchtop Dispensing Machine
Request a Quote

Compatible glues

The GT-DJ200 double station benchtop dispensing machine is compatible with solder mask, COB black glue, red glue, solder paste, UV adhesive, SILICON, EPOXY, silver glue, AB glue, conducting resin, thermal grease solder paste, instant glue and other kinds of fluid dispensing.

Features
  • Functions of drawing points, lines, rectangles, arcs and circles, continuous interpolation of irregular curves and three-axis linkage.
  • Overall correction, area correction and area array functions available. Simple machine operations.
  • Windows XP Chinese operation interface, easy to learn and operate. 80G hard disk super storage and memory capacity.
  • According to customer’s requirements, station locating pin, dispensing syringe fixture and temperature regulating device can be added.
  • Double head adjustable syringe fixture available to greatly increase dispensing efficiency.
  • 300cc large syringe or glue storage pressure barrel available to save glue replacement time.
Parameters
Model GT100/GT200
Work platform (upon request) 300mm*200mm*60mm/ 480mm*220mm*60mm
Drive motor stepper motor/servo motor(optional)
Drive method imported timing belt/high precision ball screw (optional)
Host computer PC + motion control card
Display 14″ LCD
Operation software Microcomputer control
Position precision 0.01mm
Repetition precision +/-0.005mm
Input power AC220V,50HZ
Applications
  • Semi-conductor packaging
  • PCB electronic components fixture and protection
  • Loudspeaker adhesive dispensing
  • LCD glass plate packaging
  • Chip bonding
  • Mobile phone dispensing
  • Battery box dispensing and bonding
  • Hardware parts coating and bonding
  • Automobile components coating
  • Quantitative gas or liquid coating
