Split Fiber Laser Marking Machine
- Laser wavelength 1064nm
- Marking range 50×50mm~300×300mm
- Beam quality M²<1.5
- Max. line speed 7000mm/s
The split fiber laser marking machine features a modular design as its core advantage. The separated layout of the laser control cabinet and the workstation significantly enhances equipment flexibility and heat dissipation efficiency, making it particularly suitable for factories that require frequent adjustments to production line configurations. Users can freely expand or move equipment components based on production needs, without being constrained by fixed workstations, while also reducing reliance on extensive workshop space. Whether for engraving metal components, micro-marking electronic parts, or high-precision medical device identification, this machine delivers stable and efficient output, meeting the rigorous industrial demands of multi-scenario and multi-material applications.
- Metals: Iron, steel, carbon steel, stainless steel, pure aluminum, aluminum alloy, zinc alloy, titanium alloy, brass, bronze, gold, silver, platinum
- Plastics: ABS, PVC, PE, HDPE
| Laser power | 20W, 30W, 50W, 60W, 100W, 120W, 200W |
| Laser type | fiber laser |
| Laser wavelength | 1064nm |
| Marking range | 50×50mm~300×300mm |
| Beam quality | M²<1.5 |
| Max. line speed | 7000mm/s |
| Min. character size | 0.05mm |
| Min. line width | 0.01mm |
| Cooling method | air cooling |
| Power supply | 110V~240V, 50~60Hz |
| Operating temperature | 5℃~40℃ (operation outside this range may affect performance and lifespan) |
| Machine dimensions | 320×550×700mm, 210×450×400mm |
| Package size | 800×450×770mm |
| Machine weight | 47kg |
| Package weight | 57kg |
Laser source
We provide Raycus, JPT, MAX, SUPER, and IPG laser sources for our laser equipment, featuring high pump conversion efficiency, low power consumption, and excellent beam quality.
Galvo scanner
The 7110 model galvo scanner is characterized by high-speed scanning of 7000mm/s, primarily used for laser marking and engraving. It is equipped with a dual-red-light focusing device, which significantly enhances focusing efficiency.
F-theta lens
Equipped with an F-theta lens for 1064nm wavelength, mainly used in fiber laser marking machines. Due to its longer wavelength, it offers strong energy penetration, making it suitable for marking various metal and non-metal materials. It supports long-term operation without the need for consumables to be added or replaced. Currently, we have received no user feedback regarding F-theta lens damage.
Column
Enables electric lifting and lowering, accommodating marking for workpieces of different heights without manual adjustment, greatly improving overall work efficiency.
- Fiber laser
- Portable laser control cabinet
- Work panel
- Galvo scanner
- F-theta lens
- Control card
- Laser power supply
- Laptop
- Power cord
- Safety goggles
- Foot pedal switch
- Aluminum test piece
- Hex key tool set
- Equipment warranty certificate
- Shipping accessories list
- Product catalog
