Enclosed Fiber Laser Cutting Machine with Exchange Table, RJ-6025P
Laser metal cutter for medium-thick sheet metal cutting
Our RJ-6025P enclosed fiber laser cutting machine is typically designed for efficiently processing medium-thick sheet metals of 20-45mm in thickness. It combines safety and environmental protection thanks to a full enclosure design.
- Laser power
- 3000-20000W (optional)
- Max. acceleration
- 1.5G
- Repositioning accuracy
- ±0.02mm
- Power supply
- AC 380V, 3-phase, 50/60Hz
- Max. cutting speed
- 110m/min
- Cutting area
- 2500×6000mm
optional:
1530×4050mm
2030×4050mm
2030×6050mm
2530×6050mm
2530×8050mm
-
Heavy Duty Welded Bed
The machine bed is constructed with high-strength carbon structural steel by welding. The welded bed has undergone a 600°C heat treatment, efficiently ensuring high durability of structure and enabling it able to last for 20 years without deformation.
-
Fourth Generation of Aviation Aluminum Crossbeam
The crossbeam is made from aviation aluminum alloy that has good dynamic performance. The beam is designed with honeycomb structure to provide better structural strength.
-
Exchange Worktable
The fiber laser metal cutter adopts upper and lower exchange platform which enables the worktable to be exchanged within 15 seconds, greatly improving the working efficiency.
-
Auto Focus Laser Cutting Head
The laser cutting head allows for automatically adjusting focus lens to an appropriate position by software, thus achieving automatic cutting of sheet metals with different thickness.
-
Raycus Laser Source
This laser source directly controls all types of fiber laser functions, realizing synchronous control of laser source.
-
Independent Control Cabinet
The control cabinet features a design of dustproof and vibration resistance, efficiently prolonging the service life of electrical components.
-
IPAD Screen Design
Tempered glass panel design provides high definition effect and smooth operation.
-
Newly Developed Laser Head Protective Cover
The laser head is guarded by protective cover which allows for clear observing of red light, good heat dissipation and minimal dust, efficiently avoiding cause the gas path inside the cutting head to burn.
