Double Head CNC Router
Request a Quote
//Woodworking Machinery
Wood engraving machine for efficient milling and 3D engraving of complex wood workpieces
Woodworking Machinery
- Driving motorServo motor
- Control systemA11 controller
- Spindle speed18000rpm
- Voltage380V
The double head CNC router features two independently controlled spindles, enabling simultaneous engraving on two workpieces or mirrored operations on a single piece. Compared to single-head machines, it significantly increases output without compromising accuracy. Controlled by an advanced CNC system, the router executes precise milling, cutting, and 3D engraving based on programmed patterns and dimensions, ensuring high consistency and repeatability across all parts. It is ideal for producing detailed wood carvings, reliefs, decorative panels, and complex furniture components.
Specifications
- Driving motor Servo motor
- Transmission X/Y-axis rack and pinion, Z-axis ball screw
- Control system A11 controller
- Spindle power 3.5kW×2pcs (air cooled spindle)
- Spindle speed 18000rpm
- Guide rail 25mm square linear rail
- Work table material Aluminum with PVC cover
- Voltage 380V
- Travel X-axis 1800mm Y-axis 2500mm Z-axis 200mm
Sample Showcase
