AGR Silicone Rubber Insulation Wire

AGR Silicone Rubber Insulation Wire
AGR Silicone Rubber Insulation Wire
Request a Quote

Conductor: Bare copper, tinned copper
Insulator: Silicone rubber
Rated volt.: 300/300V
Test voltage: 1500V. 15min
Rated temp.: -60℃~ 180℃

Application
AGR silicone rubber insulation wire is used where high flexibility or high temperature is required. It is therefore a suitable connection cable for home electric appliance, high voltage machines like transformers, generators, motors, traction machines.

Technical Parameters
Size Conductor Insulation thickness Wire OD Resist.
Structure OD Nominal Min. Nominal Tolerance Ω/KM
mm² NO./mm mm mm mm mm mm Max.
0.25 8/0.20 0.65 0.6 0.44 1.85 ±0.10 80.9
14/0.15
0.35 11/0.20 0.75 0.6 0.44 1.95 ±0.10 55
20/0.15
0.5 16/0.20 28/0.15 0.95 0.6 0.44 2.15 ±0.10 40.1
0.75 24/0.20 30/0.18 1.15 0.6 0.44 2.35 ±0.10 26.7
1 32/0.20 1.34 0.6 0.44 2.55 ±0.10 20
1.5 30/0.25 1.6 0.7 0.53 3 ±0.15 13.7
2.5 49/0.25 2 0.8 0.62 3.6 ±0.15 8.21
4 56/0.30 2.7 0.8 0.62 4.3 ±0.15 5.09
6 84/0.30 3.3 0.8 0.62 4.9 ±0.15 3.39
10 84/0.40 4.6 1 0.8 6.6 ±0.25 1.95
16 126/0.40 5.8 1 0.8 7.8 ±0.25 1.24

Mechanical Properties
Tensile strength: 5N/mm2 min.
Elongation at break of insulation: ≥150%
Min. bending radius: 5×OD

Characteristics
AGR silicone rubber insulation wire has very good flexibility and good performance of resistance to high temperature, ranging from -55℃ up to 180℃.
The use of silicone rubber, a high grade corona resistant insulation material, gives the cable excellent dielectric strength.
