JGG High Voltage Silicone Rubber Motor Lead Wire

JGG High Voltage Silicone Rubber Motor Lead Wire
Request a Quote

Conductor: bare copper, tinned copper
Insulator: silicone rubber
Rated volt: 3000V
Test voltage: 3000V: 9000V. 5Min
Rated Temp.: -60℃~ 180℃

Application
JGG high voltage silicone rubber motor lead wires are used where high flexibility is required and in high temperature conditions. It is therefore a suitable connection cable for home electric appliance, high voltage machines like transformers, generators, motors, traction machines.

Technical Parameters
Size Conductor Insulation thickness Cable OD Resistance
stranding OD Nominal Nominal Toler. Ω/KM
mm² No/mm mm mm mm mm Max.
0.75 24/0.20 1.14 2.0 5.14 ±0.20 26.7
1.0 32/0.20 1.32 2.0 5.32 ±0.20 20
1.5 30/0.25 1.60 2.2 6.0 ±0.25 13.7
2.0 41/0.25 1.84 2.2 6.24 ±0.25 9.9
2.5 49/0.25 2.00 2.4 6.8 ±0.25 8.21
4 56/0.30 2.60 2.4 7.4 ±0.25 5.09
6 84/0.30 3.60 2.6 8.8 ±0.25 3.39
10 84/0.40 4.60 2.6 9.8 ±0.25 1.95
16 126/0.40 5.70 2.8 11.3 ±0.25 1.24
25 196/0.40 7.1 2.8 12.7 ±0.30 0.795
35 276/0.40 8.5 2.8 14.1 ±0.30 0.565
50 396/0.40 10.3 3.0 16.3 ±0.30 0.393
70 360/0.50 12.40 3.0 18.4 ±0.30 0.277
95 475/0.50 14.50 3.2 20.9 ±0.40 0.21
120 608/0.50 16.00 3.2 22.4 ±0.40 0.164
150 756/0.50 18.00 3.5 25.0 0.60 0.132
185 925/0.50 20.00 3.5 27.0 0.60 0.108
240 1221/0.50 23.00 3.5 30.0 0.60 0.0817

Mechanical Properties
Tensile strength: 5N/mm2 min.
Elongation at break of insulation: ≥150%
Min. bending radius: 7×OD

Characteristics
JGG high voltage silicone rubber motor lead wire has very good flexibility and good performance of resistance to high temperature, range from -55℃ up to 180℃.
The use of silicone rubber, a high grade corona resistant insulation material, gives the cable excellent dielectric strength.
