90 Degree Tilt Table

Request a Quote

Website: http://corecuttingline.com/1-4-90-degree-tilt-table.html

SMIF is a specialized manufacturer of , with 90 degree tilt table as an auxiliary equipment used for tilting amorphous ribbon materials.

Hydraulic upender for tilting amorphous ribbons

As a company specializing in manufacturing equipment for transformer core production, we utilize essential equipment like 90-degree tilt tables to tilt amorphous ribbon materials. The 90 degree tilt table is primarily used for tilting operations on amorphous ribbon materials, which allows the gradual and stable transformation of horizontally placed ribbon coils into an upright position for easy hoisting in the subsequent process. Conversely, our 90 degree tilt table can also revert upright coil materials back to a horizontal position, facilitating transportation and storage.

Parameters

Machine Dimensions	1450mm(L)1300mm(B)850mm(H)
Table Size	1320mm (L) * 1300mm (B) * 350mm (H)
Tilting Angle	0 to 90 degrees, effectively hover at any angle
Tilting Force	Max: 1000kg (center of gravity height: 600mm)
Tilting Speed	90 degrees/15 seconds to 30 seconds (stepless adjustable)
Primary Power Source	Hydraulic system, double hydraulic cylinders
System Working Pressure	10—16 MPa
Operating Mode	Electric control
Power Supply	AC220V, 50HZ, 1.5kW

FAQs

In an amorphous core production line, the 90 degree tilt table is primarily used to slowly and steadily tilt horizontally placed amorphous alloy ribbon coil materials into an upright position or to revert upright coil materials to a horizontal position, facilitating handling, hoisting, transportation, or storage in subsequent processes.

Our amorphous ribbon core production line is mainly used by amorphous ribbon manufacturers, transformer core manufacturers, and power transformer manufacturers.

Our equipment can process amorphous cores for transformers, filter cores, DC immunity cores, and permalloy cores, among others.

Our amorphous core cutting line is primarily designed for rectangular ribbon shearing, with a cutting width ranging from 140mm to 220mm and a single-blade cutting length ranging from 300mm to 10,000mm.

Compared to other soft magnetic materials, our amorphous ribbon cores offer a wider range of high-frequency properties and lower core losses, including:

High permeability
High magnetic density
Reduced distribution and core losses
Wide range of frequency properties
Low coercivity forces
Low no-load loss
Low temperature rise
Excellent resistance to corrosion
High harmonic wave tolerances

Amorphous cores are primarily used in amorphous core transformers, inductors, drivers, motors, reactors, and any devices requiring high-frequency, low-loss performance.
