90 Degree Mold Flipper / Mold Rotator Manufacturer

90 Degree Mold Flipper / Mold Rotator

Request a Quote

View All: http://moldpresscn.com/2-1-90-turning-mold-reversing-machine.html

The 90 degree turning mold reversing machine can be installed directly on the ground, thus allowing plant employees to carry out 90 degree turns of molds in an easy, quick manner. It is especially suitable for medium and large molds. Compared to a traditional crane lifting method, this machine has a higher mold reversal efficiency, thus reducing operator intensity, and prevents the factory floor from becoming damaged due to heavy molds.

Mold reversing process

Type selection

SXF-10

Overturn capacity: 10 ton
Table size: 1400×1300 mm
Table height: 740 mm
Center height: 490 mm

SXF-15

Overturn capacity: 15 ton
Table size: 1600×1500 mm
Table height: 740 mm
Center height: 490 mm

SXF-20

Overturn capacity: 20 ton
Table size: 2000×1600 mm
Table height: 870 mm
Center height: 610mm

SXF-30

Overturn capacity: 30 ton
Table size: 2200×1800 mm
Table height: 980 mm
Center height: 670mm

SXF-50

Overturn capacity: 50 ton
Table size: 2500×2000 mm
Table height: 1170 mm
Center height: 720 mm

SXF-70

Overturn capacity: 70 ton
Table size: 3200×3200 mm
Table height: 1530 mm
Center height: 1180 mm

Items Model		SXF-10	SXF-15	SXF-20	SXF-30	SXF-50	SXF-70
Overturn capacity	T	10	15	20	30	50	70
Table area	mm	1400×1300	1600×1500	2000×1600	2200×1800	2500×2000	3200×3200
Table height	mm	740	740	870	980	1170	1530
Center height	mm	490	490	610	670	720	1180
External dimension (length×width×high)	mm	1910×1500 ×2040	2157×1600 ×2240	2360×2100 ×2470	2680×2300 ×2780	3000×2600 ×3170	4800×3300 ×4745
Electrical power	kW	4	5.5	7.5	11	22	22
Weight	T	3.2	3.8	6.5	9.5	15.5	25.3

Note: The technical parameters are subject to change without prior notice.

Features

Easy operation, ensuring minimal effort and training.
Built on our extensive experience of over 15 years in the development and production of mold flippers.
An economical and practical solution.

Indian customer VALEO using scene
