U-channel aluminum extrusions

Zhongpeng offers a range of 6000-series aluminum U-channels, including alloys 6060, 6061, 6063, 6082, 6005, and 6005A. These aluminum channels provide excellent corrosion resistance and processability, with options for precision cutting to meet application-specific requirements.

A variety of surface finishes are available, including anodizing, polishing, electroplating, sandblasting, and powder coating, ensuring durability and aesthetic appeal across architectural and industrial environments.

Aluminum U-channels are widely used for edge protection, decorative trims, railings, and ladders, as well as in cabinet frames, wardrobes, doors, windows, electronic enclosures, and display fixtures.

Available Sizes

Product No.	Side A (mm)	Base B (mm)	Thickness (mm)	Weight (kg/m)	Extrusion Press Capacity	Alloy & Temper
ZWJ-WLB-502	2.7	6.8	0.7	0.020	500T	6063-T5
BH-023	12	7	1	0.078	500T	6063-T5
QYH-23	13	7.6	1.1	0.093	500
TP-1870	13	7.6	1.1	0.093	500
ZW_D055012	8	8	1	0.059	500	6060-T66
YDKM-SY-65	14	8	1.5	0.134	500
SOMA_A001196	20	8	2	0.229	500	6060-T66
ZW_D055018	12	8.6	1.3	0.105	500T	6060-T66
ZS803-04	8.9	8.9	0.8	0.054	500T
TP-07B	9	9	0.7	0.048
YDKM-DF-26	13.8	9.2	2.0	0.177	500	6063-T6
ZW_D010530	9.525	9.525	1.63	0.111	500T	6063-T6
ZW_D055019	8	10	1.3	0.082	500T	6060-T66
ZW_D030927	8	10	1.5	0.093	500T	6060-T66
SOMA_A000029	10	10	1	0.076	500	6060-T5
TP-07	10	10	1.2	0.089	500
CHD_A000609	10	10	1.5	0.109	500T	6060-T66
ALD_D000397	10	10	1.6	0.116	500	6060-T5
SOMA_A001124	10	10	2	0.140	500	6060-T6
SOMA_A000031	15	10	1.5	0.150	500	6060-T5
ZW_D060579	15	10	2	0.194	660T	6060-T66
CHD_A000249	20	10	2	0.248	500T	6060-T66
ZWJ-WLB-902	3	10.8	0.7	0.029	500T	6063-T5

Material Selection Guide

Alloy	Key Properties	Typical Applications
6060U Aluminum Channel	Corrosion resistance, machinability, and stable surface finish.	Industrial frames, guide rails, support structures, light assembly components.
6063U Aluminum Channel	Corrosion resistance and uniform surface quality; suitable for anodizing.	Architectural decoration, door and window frames, curtain walls, interior finishing.
6061U Aluminum Channel	Durability, corrosion resistance, and weldability.	Industrial machinery frames, load-bearing supports, structural components.
6082U Aluminum Channel	Mechanical strength and corrosion resistance.	Marine fittings, transportation components, heavy-duty frameworks.
6005AU Aluminum Channel	Durability, corrosion resistance and reliable performance.	Industrial machinery, rail systems, lightweight structural parts.
6005U Aluminum Channel	Durability, corrosion resistance with stable workability.	Industrial supports, transport facilities, mechanical frameworks.
