MV03 Floating / Modulating Valve
This product has been discontinued and removed from our shelves.
Ball Float Valve/ Valve Float/ Mechanical Valve
General
The MV03 series floating/modulating valves are widely used in central air-conditioning cool/heat water systems. It can precisely control the flow of the cooling/heating medium depending upon the requirements of the given application. It prevents sudden heat changes that can lead to undesired temperatures or energy loss.
Features
● Bi-directional floating proportional control
● High precision and sensitivity of temperature control
● Various AC voltages for selection, such as 24V, 110V and 220V,etc
● Timing protection device (24Vac working power supply, it can be assembled for optional), to ensure motor reliability and durable life
● Built-in electronic card (24V working power supply) can receive 0~10V (for model MV03…B) or 4~20mA(for model MV03…EC) DC input control signal, and provide proportional control
● The valve actuator and valve body feature a tight lock connection. The actuator can be installed after the installation of the valve body. It has flexible and convenient assembly.
