N15 Series LED Headlight Bulb
Request a Quote
Features
- The heat sink has a diameter of 32mm and a height of 32mm, with a power output of 55W, ensuring effective cooling for prolonged use.
- 3570 LED Chips with Dual Superconducting Heat Pipes: Featuring 6*51 3570 LED chips, dual superconducting heat pipes, and unique S-shaped cooling fins made from AL6063 material (European standard), this design improves heat dissipation for optimal performance.
- The 1.5mm double-sided copper base plates are perfectly welded to the dual superconducting heat pipes, enhancing heat transfer. The built-in driver and smart temperature control system protect the LED chips for longer lifespan.
- Compatible with both small and large trucks (12V/24V), the bulb features EMC and decoding functions, providing vehicle compatibility and performance protection with patent protection.
Specification
| Series | N15 | ||||||
| Model | N15 H1 | N15 H4 | N15 H7 | N15 H11 | N15 9005 | N15 9006 | N15 9012 |
| Voltage (V) | DC9-100 | ||||||
| Power (W) | 55 | ||||||
| Luminous Flux (lm) | 4500 | ||||||
| Color temperature (K) | 6500 | ||||||
| Driver | Built-in driver | ||||||
| Fan | Yes | ||||||
