15W Drive Motor, PMDC Brushless Motor GF033A
Request a Quote
Your Motion
Application: massage gun
Technical Specifications
| Rated Power (W) | 15 |
| Max. Power (W) | 20 |
| Rated Voltage(V) | 12 |
| No-load Current(A) | < 0.4 |
| No-load Revolution (RPM) | 3100±5% |
| Rated Torque (mN•m/1000) | 55 |
| Max. Torque (mN•m/1000) | 120 |
| Rated Revolution (RPM) | 2500±5% |
| Rated Current(A) | ≤2.5 |
| Rated Efficiency (%) | ≥60 |
| Working Cycle (min.) | S2-60 |
| Insulation Class | E |
| Protection Level | IP00 |
| Length (mm) | 41.5 |
Note: we can customize any brushless DC drive motors according to your application requirements and working conditions.
