GP1360
Bag-top fold-over device for folding woven bags or laminated bags prior to sewing
This bag-top folding machine is a chain-driven stainless steel folding device designed to feed the bag all the way through to the sewing section. It is suitable for packaging lines in the grain, chemical, fertilizer, and feed industries, where it supports stable folding and infeed before stitching.
Applicable Bag Types
Woven bags
Paper–plastic laminated bags
Technical Specifications
| Folding width | 30–40mm |
| Bag feeding speed | 7–18m/min |
| Applicable bag thickness | 4–6 layers of woven bags |
| Gear reducer ratio | 1:20 |
| Motor power | 250W |
| Machine weight | 61kg |
| Machine dimensions (L×W×H) | 1380×465×310mm |
Specifications are subject to change without prior notice.
Product images may differ from the actual model configuration.
