UN5018 Fixed Focus Lens, 1/2.8' Sensor, 2.0mm, F2.0 Aperture
Request a Quote
Video Conference Lens
- 4K HD resolution for fine details and recognition accuracy
- F2.0 large aperture for clear, low-noise images
- 95° wide field of view for wide coverage
- -2.3% low distortion for true-to-life images
Designed for video conferencing and live streaming, UN5018 fixed focus lens features a 1/2.8″sensor and an F2.0 large aperture, delivering 4K ultra-high-definition visuals with crisp close-ups and natural skin tones. Its 97.5° wide-angle field of view captures multi-participant scenes, while –2.3% ultra-low distortion preserves true-to-life imaging without deformation, ensuring both speakers and product details stand out clearly. With a compact, easily integrated optical design, the UN5018 offers a high-compatibility, low-distortion solution ideal for enterprise conferencing, online education, and live-commerce applications.
Specification
- Part Number: UN5018
- Sensor Type: 1/2.8'
- Focal Length: 3.0mm±5%
- FNo.: 2.0±5%
- Total Length: 14.75±0.3 mm
- Mechanical BFL: 3.73±0.2 mm
- Max Image Circle: ∅7.0mm
- Optical FOV (D): 95°±3°
- Optical FOV (H): 85.9°±3°
- Optical FOV (V): 54.4°±3°
- Relative Illumination: ≥35%
- Distortion: ＞-2.3%
- Chief Ray Angle: 19±3°
