UN0516 Fixed Focus Lens, 1/2.8' Sensor, 3.5mm, F1.1 Aperture

UN0516 Fixed Focus Lens, 1/2.8' Sensor, 3.5mm, F1.1 Aperture
Request a Quote

Security Camera Lens

  • F1.1 ultra-large aperture delivers clear, detailed images day and night.

UN0516 fixed focus lens adopts an ultra-large F1.1 aperture, delivering night vision clarity comparable to daytime and exceptional detail capture.
Equipped with a 1/2.8' sensor and a 3.5 mm focal length, it offers a 115° diagonal wide-angle field of view for broader coverage and fewer blind spots.With day-night co-focus technology, it maintains sharp, precise focus around the clock without the need for repeated adjustments.
Even in low-light environments, the lens ensures high brightness and low noise, making it ideal for home security, smart monitoring, and other 24/7 surveillance applications, providing reliable protection anytime, anywhere.

Specification
  • Part Number: UN0516
  • Sensor Type: 1/2.8'
  • Focal Length: 3.5±5%mm
  • FNo.: 1.1±10%
  • Total Length: 22.5±0.3mm
  • Mechanical BFL: 4±0.2mm
  • Max Image Circle: Ø7.2mm
  • Optical FOV (D): 115°±3°(∅6.388mm)
  • Optical FOV (H): 97°±3°(∅5.568mm)
  • Optical FOV (V): 52°±3°(∅3.132mm)
  • Relative Illumination: ≥43%
  • TV Distortion: ≥-16%
  • Max Chief Ray Angle: 13°±3°
