Ultrasonic Cut Single Machines
Request a Quote
Mingui's Ultrasonic cut single machines utilize 30k ultrasonic waves to cut labels. It has no noise and holds high welding speed.
Minghui also provides MHQ-70C low-speed ultrasonic label cutting machines, MHQ-70G high-speed ultrasonic label cutting machines, and MHQ-70X multifunction ultrasonic label cutting machines.
- The MHQ-70C needs to adjust the cutting knife to control its pressure.
- MHQ-70G can easily set the cutting knife pressure on the operation panel.
- MHQ-70X cuts materials at 360° and it achieves single cutting, trapezoidal cutting and parallel inclined cutting.
This label cutting machine also provides functions like waste charge, pressing lines, and cutting lines.
Specifications
| Model | MHQ-70C | MHQ-70G | MHQ-70X |
| Cutting Length | 1-500mm | 1-500mm | 50-999mm |
| Cutting Width | 1-70mm | 1-70mm | 5-70mm |
| Cutting Speed | 500pcs/Min (5cm) | 700pcs/Min (5cm) | 0-500pcs/Min |
| Power | 220V/1.5KW | 220V/1.8KW | 220V／2.5KW |
| Weight | 150Kg | 175Kg | 190Kg |
| Dimensions | 1400×550×1300mm | 1600×600×1200mm | 1100×600×1550mm |
You can contact us for a quotation or with any questions you may have on this product.
