YD32 Hydraulic Presses

4-post hydraulic press for deep drawing, bending, forming, cutting, blanking and flanging operations

Nominal capacity 1000kN to 10000kN
Return capacity 160kN to 800kN
Slide stroke 600mm to 1400mm
Table size (L-R×F-B) 700×700mm to 1800×1600mm

The YD32 4-column universal hydraulic press is a standard and widely used four-post hydraulic press designed for deep drawing, bending, forming, cutting, blanking, and flanging operations. Known for its reliability, stable performance, and cost-effectiveness, this machine is ideal for metal, plastic, rubber, powder metallurgy, and composite material processing.

With a nominal capacity ranging from 1,000kN to 10,000kN and slide strokes from 600mm to 1,400mm, the 4-column universal hydraulic press delivers powerful and flexible performance. The table sizes range from 700×700mm to 1800×1600mm, supporting a wide range of part sizes and forming applications.

Built with a computer-optimized four-column structure, the press offers simplicity, durability, and strong adaptability. A frame-type structure is also available for enhanced rigidity and off-center load resistance. The hydraulic system features an integrated cartridge valve system for smooth, reliable operation with minimal hydraulic shock and reduced leakage points.

The bottom beam includes an ejector cylinder that enables three working modes: ejection, non-ejection, and reverse drawing. Operators can select between pressure-based and stroke-based forming through the control panel.

Applications

Metal forming: automotive body parts, appliance housings, metal containers
Plastic products: molded plastic parts, containers, lids, sheets, insulation components
Rubber parts: seals, rubber pads, tires
Powder metallurgy: compacting metal powder and ceramic parts
Composite materials: composite panels, insulation boards

Key Features

Computer-optimized four-post structure for economical, practical use
Optional frame body structure with excellent rigidity and high accuracy
Cartridge valve hydraulic control system for long service life and minimal hydraulic impact
Dual forming modes: pressure-based and stroke-based
Integrated ejector cylinder supports various forming cycles, including reverse drawing

Specifications

Model		Unit	YD32-100	YD32-200	YD32-315	YD32-400	YD32-500	YD32-630	YD32-800	YD32-1000
Nominal capacity of main cylinder		kN	1000	2000	3150	4000	5000	6300	8000	10000
Max. working pressure		MPa	25	25	25	25	25	25	25	25
Return capacity		kN	160	240	300	350	380	640	720	800
Ejector capacity		kN	500	800	1000	1000	1250	1500	1500	2000
Slide stroke		mm	600	700	800	800	900	900	1000	1400
Ejector stroke		mm	200	200	200	250	250	250	300	300
Opening height (daylight)		mm	900	1100	1250	1250	1500	1500	1600	2000
Table size	Left-Right	mm	700	930	1250	1300	1400	1600	1600	1800
Table size	Front-Back	mm	700	900	1200	1300	1400	1400	1400	1600
Slide speed	Descent	mm/s	150	150	150	150	150	200	200	200
	Pressing	mm/s	10-16	10-20	10-20	8-15	8-15	8-15	10-16	10-18
	Return	mm/s	150	160	160	160	150	150	150	150
Main motor power		kW	7.5	18.5	22	22	30	44	60	74

Note: Special specifications can be custom-designed and manufactured according to your requirements.

Download

Our product brochure

The 4-column universal hydraulic press provides dependable performance and versatility across a wide range of forming applications. Contact us to find the best configuration for your production needs.
