H-Frame Hydraulic Press
YD34 Hydraulic Presses
- Nominal capacity 1000kN to 10000kN
- Return capacity 160kN to 800kN
- Max. slide stroke 600mm to 1400mm
- Table size (L-R×F-B) 700×700mm to 1800×1600mm
The YD34 H-frame hydraulic press is a servo-controlled hydraulic press designed for deep drawing, bending, forming, cutting, blanking, and flanging. Built with a fully welded frame structure, this press delivers exceptional strength, rigidity, and long-term stability making it ideal for metal forming and forging applications across a variety of materials and industries.
With a nominal capacity from 1,000kN to 10,000kN and a maximum slide stroke between 600mm and 1,400mm, the H-frame hydraulic press handles a wide range of forming operations with precision. The press uses a four-sided, eight-surface adjustable guide rail with automatic lubrication, ensuring excellent guiding performance and long-lasting accuracy.
Its hydraulic system is equipped with compact cartridge valves that reduce hydraulic resistance and energy loss. The servo system actively regulates working speed and system pressure while offering optional remote-control functionality.
- Metal forming: automotive axle parts, general stamping components, small forged blanks
- Composite materials: SMC molded parts, electrical insulation boxes
- Rubber parts: seals, pads, tires
- Powder metallurgy: compacted metal and ceramic components
- Fully welded frame with computer-optimized structure for high strength and simple maintenance
- Adjustable four-corner, eight-surface guide rail ensures high precision retention
- Compact cartridge valve hydraulic control system offers reliability, longevity, and reduced hydraulic shock
- Forming modes include both stroke-based and pressure-based control, selectable via operator panel
- Ejector cylinder integrated into the lower beam
- Optional auxiliary units such as quick die change systems available for increased productivity
| Model | Unit | |||||||||
| Nominal capacity of main cylinder | kN | 1000 | 2000 | 3150 | 4000 | 5000 | 6300 | 8000 | 10000 | |
| Max. working pressure | MPa | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | |
| Return capacity | kN | 160 | 240 | 300 | 350 | 380 | 640 | 720 | 800 | |
| Ejector capacity | kN | 500 | 800 | 1000 | 1000 | 1250 | 1500 | 1500 | 2000 | |
| Slide stroke | mm | 600 | 700 | 800 | 800 | 900 | 900 | 1000 | 1400 | |
| Ejector stroke | mm | 200 | 200 | 200 | 250 | 250 | 250 | 300 | 300 | |
| Opening height (daylight) | mm | 900 | 1100 | 1250 | 1250 | 1500 | 1500 | 1600 | 2000 | |
| Table size | Left-Right | mm | 700 | 900 | 1200 | 1300 | 1400 | 1600 | 1600 | 1800 |
| Front-Back | mm | 700 | 900 | 1200 | 1300 | 1400 | 1400 | 1400 | 1600 | |
| Slide speed | Descent | mm/s | 150 | 150 | 150 | 150 | 150 | 200 | 200 | 200 |
| Pressing | mm/s | 10-16 | 10-20 | 10-20 | 8-15 | 8-15 | 8-15 | 10-16 | 10-18 | |
| Return | mm/s | 150 | 160 | 160 | 160 | 150 | 150 | 150 | 150 | |
| Main motor power | kW | 7.5 | 18.5 | 22 | 22 | 30 | 44 | 60 | 74 | |
Note: Special specifications can be custom-designed and manufactured according to your requirements.
Our product brochure
The YD34 h-frame hydraulic press provides robust, precise, and efficient forming capabilities with high automation potential. Contact us to explore how it can optimize your production line.
