Preheating Oven

Preheating Oven
Request a Quote
Application  PCB pre-heating
Power supply AC380V 3φ 50Hz
Temperature range Room temperature~75℃ needs approximate 35 minutes.
Temperature uniformity ±2% (tested without loading)
Dimension L9956 mm × W2250 mm × H2786mm
Feeding zone: 1549mm(2 STEPS)
Infeed buffering zone: 762mm(1 STEP)
Heating zone: 4572 mm (divided into 6 sections)
Cooling zone:1524mm (2 STEPS)
Discharging zone: 1549mm (2 STEPS)
Step motor: 762mm/STEP
Oven internal height: H850mm
Heating temperature Max. 150℃, normally use 75℃
Configuration Φ150mm exhaust duct, exhaust on both sides with 90℃ adjustable exhaust damper.
Feeding from left to right (facing to the control panel), and equipped with multipoint temperature sensor.(6 points in total)
