Pangu offers roller shutter doors with remote controls, which are specially designed for family garages. The maximum width will allow access for two cars, and because of the compact structure and flexible operation, the garage roller shutter door requires only a small installation space to reduce the amount of space it occupies.

Compared to traditional shutter doors, the roller shutter doors are light, quiet, and fast. Users can choose the colors, and we also offer a multi-layer baking varnish and a strong rust resistance. In addition, we install soundproof tapes and guides on both sides of the door panel, ensuring operation is quiet.

• 180mm: The distance from the door hole to the ceiling will be greater than 180mm
• Power off emergency trip device
• Motor rail
• Smart garage door opener remote controller
• Bracket
• "┌" form orbit
• Torsion spring
• Polyurethane insulation board
• The door side distance shall be greater than 60mm.

• Curtain plate thickness: 2mm
• Guide rail thickness: over 3mm
• Average noise: below 70 decibels
• Operating speed: 3m/min
• Refractory time: 4 hours
• Slot smoke amount: below 0.18m³/min

The roller shutter door sides are equipped with a door opener, which allows for adjustment of the opening/closing force. Roller shutter doors can also be connected to a wall switch, infrared protection device, charging reserve power and pry alarm power supply.

The roller shutter door is equipped with an internal tubular motor, which is not only small in size and easy to install, but also has a lower noise than an ordinary motor.

The internal torsion spring balancing system allows the door to easily open and close, even in the event of a sudden power loss. This system also lowers the burden on the motor by reducing the working load, and thus, extends the service life.

Equipped with an emergency device for power failure, the roller shutter door is connected to the clutch end wire rope and the clutch limit of the door opener, both of which can be used to manually open the garage door during a power failure.

Equipped with an electric and manual starting and closing devices, when the roller shutter door encounters fire sensing signals such as high temperature and thick smoke, it will automatically descend or stop.
