Tunnel Metal Detector
Request a Quote
- Soonk's tunnel metal detectors are designed to detect iron, aluminum and stainless steel contaminants in food and toys, ensuring a better stability and sensitivity than other equipment.
Features
- The metal sensor is installed on the equipment side to avoid interference with machine drive system parts.
- Adjustable sensitivity to ferrous and non-ferrous metal.
- Two LEDs display the signals for ferrous and non-ferrous metal contaminants, thus ensuring efficient operation.
- Strong inhibition to aquatic products, frozen food and pickled food.
Technique specification
| Model | 4012 | 4015 | 4020 | 4025 | 5025 |
| Sensitivity to iron | 0.8 | 1.0 | 1.5 | 1.5 | 2.0 |
| Sensitivity to stainless steel | 1.5 | 2.0 | 3.0 | 3.0 | 3.5 |
| Detection height (mm) | 120 | 150 | 200 | 250 | 250 |
| Detection width (mm) | 400 | 400 | 400 | 400 | 400 |
| Total power | 220V,50Hz/60Hz,0.2kw | ||||
| Detection speed | 20 | 20 | 20 | 20 | 20 |
| Alarm | Alarm to stop or reject (optional) | ||||
If you are interested in our tunnel metal detector, please feel free to contact us!
