YM130/1 YM130/2

Dough Processing Equipment

Advantages of Dough Roller Machine
  • The dough roller machine utilizes a belt drive and a chain drive reduction system, delivering powerful performance in a compact structure. It is easy to operate, produces low noise, and operates with high efficiency.
  • The dough rolling speed reaches up to 125 rpm, producing smooth dough sheets. Repeated folding and rolling of the dough enhances gluten development and elasticity.
  • Equipped with a standard-compliant control system, the dough roller machine features a user-friendly speed adjustment, broadening its range of applications.
  • Standard features include an emergency stop button and an oil-resistant rubber-sheathed power cable.
  • The dough roller is CE/ISO certified.
Specifications
Model Dimensions (mm) Dough thickness range (mm) Power (kW) Roller speed (r/min) Machine weight (kg) Voltage (V) Material Roller size (mm)
YM130/1 600×930×1100 1-18 1.5 125 119 220/380, 3P Stainless steel ⌀112×300
YM130/2 600×930×1100 1-18 1.5 125 119 220/380, 3P 304 stainless steel Ø112×300
Features
  • The emergency stop button allows immediate halting of the machine in case of improper operation.
  • The frame and protective covers are made of stainless steel, while the hopper and dough contact surfaces are constructed from 304 stainless steel, fully complying with food safety and hygiene standards.
