Heavy-oil Marine Engine

Request a Quote

Website: http://jinanengine.com/4-Heavy-oil.html

HIGH QUALITY AND EFFICIENCY WIDE POWER RANGE

Description of Heavy-oil Marine Engine

Rated power: 380~720KW
Fuel consumption: ≤204 g/kW.h
Oil consumption: ≤1.2 g/kW.h
Overall dimensions: 2995m×1133m×1754m
3175m×1208m×2055m
Net weight: 3960kg and 4500 kg

Applications

With lower cost of heavy-oil, this propulsion engine is used extensively in ships and generating sets etc.

Click Here to

Technical Specification of Heavy-oil Marine Diesel Engine

Model	Rated power (kW)	Rated rpm (r/min)	Fuel consumption (g/kW.h)	Oil consumption (g/kW.h)	Overall dimensions (mm)	Net weight (kg)
G6190Z LC G6190Z LCZ-R	540	1450	≤204	≤1.2	2995×1133×1754	3960
G6190Z LC-1 G6190Z LCZ-1R	450	1200	≤204	≤1.2	2995×1133×1754	3960
G6190Z LC-2 G6190Z LCZ-2R	380	1000	≤202	≤1.2	2995×1133×1754	3960
8190ZLCZ-R 8190ZLC	720	1450	≤204	≤1.2	3175×1208×2055	4500
8190ZLCZ-1R 8190ZLC--1	600	1200	≤202	≤1.2	3175×1208×2055	4500
8190ZLCZ1-1R 8190ZLC1--1	490	1200	≤202	≤1.2	3175×1208×2055	4500
8190ZLCZ-2R 8190ZLC--2

CNPC JICHAI was formed in 1920, we are a prestigious brand in China and is a global leader in internal conbustion engine and generator set manufacturing. Our power solutions are designed to improve your performance and productivity.
