B50 Electric Forklift
Request a Quote
Lithium battery forklift truck with rated load capacity of 5000kg
- Rated load capacity
5000kg - Load center distance
500mm - Driving mode
Seated - Overall length (with forks)
4510mm
Specifications
| Power type | Lithium battery |
| Rated load capacity | 5000kg |
| Load center distance | 500mm |
| Driving mode | Seated |
| Overall length (with forks) | 4510mm |
| Overall length (without forks) | 3275mm |
| Overall width | 1430mm |
| Mast lowered height | 2280mm |
| Overhead guard height | 2140mm |
| Max. working height | 4210mm |
| Wheelbase | 2265mm |
| Front overhang | 490mm |
| Rear overhang | 485mm |
| Front wheel track width | 1150mm |
| Rear wheel track width | 980mm |
| Min. ground clearance | 180mm |
| Fork adjustment range | 300-1380mm |
| Mast tilt angle (front/rear) | 6°/12° |
| Max. lifting speed (no load) | 315mm/s |
| Max. lifting speed (full load) | 280mm/s |
| Max. travel speed (no load) | 13km/h |
| Max. travel speed (full load) | 13km/h |
| Max. gradeability (full load) | 15% |
| Total machine weight | 5740kg |
| Number of wheels | 2/2 |
| Tire type (front/rear) | Pneumatic tire/solid tire |
| Tire size (front) | 250-15 |
| Tire size (rear) | 8.25-15 |
| Service brake | Hydraulic brake |
| Parking brake | Manual brake |
| Drive motor power | 22.6kW |
Features
- Equipped with a lithium iron phosphate battery with over 4,000 charge cycles, maintaining more than 75% capacity for prolonged usage.
- Permanent magnet synchronous high-torque motor delivers strong power, higher efficiency, and energy savings.
- High-voltage platform enables full charging in just one hour, minimizing power loss and extending overall battery life.
“The “Full-System Emergency Power Cutoff” function allows immediate disconnection of the vehicle control system and BMS power, ensuring maximum safety and reliability.
