Automatic Ribbon Bow Making Machine

Request a Quote

Website: http://solution-textile.com/6-automatic-ribbon-bow-making-machine.html

Automatic ribbon bow making machine is designed for producing decorative bows and is widely used in industries such as garments, gift packaging, and accessories.

Parameters

	JHT-20 Ribbon Bow Making Machine	JHT-60 Bow Making Machine (Center-Wrapped)	JHT-80 Ribbon Bow Making Machine (Wire-Tied)
Model	JHT-20	JHT-60	JHT-80
Width of ribbon	3–10 mm	12–25 mm	6–12 mm
Length of ribbon	85–200 mm	250–330 mm	90–140 mm
Power consumption	0.7 kWh	0.7 kWh	0.7 kWh
Efficiency	±1800 pcs/h (standard)	±600 pcs/h (standard)	±700 pcs/h (standard)
Drive system	Motor & pneumatic
Air pressure	0.6 MPa	0.6 MPa	0.6 MPa
Machine size	1100 × 900 × 1650 mm	1400 × 1100 × 1650 mm	1150 × 850 × 1400 mm
Weight	200 kg	200 kg	200 kg
Noise level	75 dB	75 dB	75 dB
Angle	Adjustable	Adjustable	Adjustable
Motor system	Servo motor & stepper motor
Machine power	1.5 kW	2 kW	2 kW
Motor power	1 kW	1.5 kW	1.5 kW
Voltage	220V	220V	220V
