Winding Machine Parts

Request a Quote

View All: http://solution-textile.com/8-machine-parts.html

In addition to winding machines and other related products, we also provide spools and bobbins of different materials for use in covering machines as auxiliary tools.

1. High press injection aluminum alloy bobbin

This aluminum alloy bobbin is formed by die casting, followed by precise turning and high-speed dynamic balance correcting, which guarantees the stability of high-speed operation and prolong the service life of the aluminum ingot.

Model	Traverse Length	Flange Diameter	Flange Diameter	Barrel Diameter
P-01	150	90	90	35.5
P-02	150	84	84	35.5
P-03	140	103	103	53.5
P-04	140	90	90	40
P-05	135	76	76	35.5

2. Super hard aluminum bobbin

This bobbin is made from high-strength aluminum alloys, molded integrally through precise turning, and subject to high-speed dynamic balance correcting, which guarantees the stability of high-speed operation and prolongs the service life of the bobbin.

Model	Traverse Length	Flange Diameter	Flange Diameter	Barrel Diameter
PS-01	150	90	90	35.5
PS-02	150	84	84	35.5
PS-03	140	90	90	35.5
PS-04	140	90	90	40
PS-05	135	76	76	35.5

3. Combinated material Italian twister spools, aluminum spool bobbin

This bobbin is made from high-strength aluminum alloys and polyester materials, which not only guarantees the strength and precision, but also effectively saves energy consumption.

Model	Traverse Length	Flange Diameter	Flange Diameter	Barrel Diameter
PC-01	180	105	105	45
PC-02	180	95	95	45
PC-03	150	105	105	40
PC-04	140	90	90	40
PC-05	135	84	84	40
