Solid Carbide Drill, with Coolant Holes, DIN6537

Solid Carbide Drill, with Coolant Holes, DIN6537
Solid Carbide Drill, with Coolant Holes, DIN6537
Solid Carbide Drill, with Coolant Holes, DIN6537
Request a Quote
View All: http://metalworking-tool.com/9-8-emh08-solid-carbide-drill.html
  • High Speed drills for precise and efficient drilling on general steel, tool steel, cast steel, cast iron, malleable cast iron, chilled cast iron, titanium, non-ferrous heavy metal, abrasive plastic, etc.
  • Special twister flute, self-centering and excellent performance
  • Efficient chip removal during the machining of soft and hard metal
  • Imported raw materials offer excellent tool life
Application
Product Specifications
Coating AITiN /TiALN /TiSiN/TiN HRC HRC35/45/55
Helix Angle 30° Shank Cylindrical H6
Point Angle 140° Tolerance on Cutting Diameter 0-0.030
High Speed Steel Drills with Coolant Hole, 5D (UNT-EMH08 )
Unit: mm
UNT EDP # Click to Order Mill Dia.
D1 		Flute Length
L1 		O.A.L.
L2 		Flutes
EMH08010 1.0 3 8 55
EMH08011 1.1 3 12 55
EMH08012 1.2 3 12 55
EMH08013 1.3 3 12 55
EMH08014 1.4 3 12 55
EMH08015 1.5 3 16 55
EMH08016 1.6 3 16 55
EMH08017 1.7 3 16 55
EMH08018 1.8 3 16 55
EMH08019 1.9 3 16 55
EMH08020 2.0 4 21 57
EMH08021 2.1 4 21 57
EMH08022 2.2 4 21 57
EMH08023 2.3 4 21 57
EMH08024 2.4 4 21 57
EMH08025 2.5 4 21 57
EMH08026 2.6 4 21 57
EMH08027 2.7 4 21 57
EMH08028 2.8 4 21 57
EMH08029 2.9 4 21 57
EMH08030 3.0 6 21 66
EMH08031 3.1 6 28 66
EMH08032 3.2 6 28 66
EMH08033 3.3 6 28 66
EMH08034 3.4 6 28 66
EMH08035 3.5 6 28 66
EMH08036 3.6 6 28 66
EMH08037 3.7 6 28 66
EMH08038 3.8 6 36 74
EMH08039 3.9 6 36 74
EMH08040 4.0 6 36 74
EMH08041 4.1 6 36 74
EMH08042 4.2 6 36 74
EMH08043 4.3 6 36 74
EMH08044 4.4 6 36 74
EMH08045 4.5 6 36 74
EMH08046 4.6 6 36 74
EMH08047 4.7 6 36 74
EMH08048 4.8 6 44 82
EMH08049 4.9 6 44 82
EMH08050 5.0 6 44 82
EMH08051 5.1 6 44 82
EMH08052 5.2 6 44 82
EMH08053 5.3 6 44 82
EMH08054 5.4 6 44 82
EMH08055 5.5 6 44 82
EMH08056 5.6 6 44 82
EMH08057 5.7 6 44 82
EMH08058 5.8 6 44 82
EMH08059 5.9 6 44 82
EMH08060 6.0 6 44 82
EMH08061 6.1 8 53 91
EMH08062 6.2 8 53 91
EMH08063 6.3 8 53 91
EMH08064 6.4 8 53 91
EMH08065 6.5 8 53 91
EMH08066 6.6 8 53 91
EMH08067 6.7 8 53 91
EMH08068 6.8 8 53 91
EMH08069 6.9 8 53 91
EMH08070 7.0 8 53 91
EMH08071 7.1 8 53 91
EMH08072 7.2 8 53 91
EMH08073 7.3 8 53 91
UNT EDP # Click to Order Mill Dia.
D1 		Flute Length
L1 		O.A.L.
L2 		Flutes
EMH08074 7.4 8 53 91
EMH08075 7.5 8 53 91
EMH08076 7.6 8 53 91
EMH08077 7.7 8 53 91
EMH08078 7.8 8 53 91
EMH08079 7.9 8 53 91
EMH08080 8.0 8 53 91
EMH08081 8.1 10 61 103
EMH08082 8.2 10 61 103
EMH08083 8.3 10 61 103
EMH08084 8.4 10 61 103
EMH08085 8.5 10 61 103
EMH08086 8.6 10 61 103
EMH08087 8.7 10 61 103
EMH08088 8.8 10 61 103
EMH08089 8.9 10 61 103
EMH08090 9.0 10 61 103
EMH08091 9.1 10 61 103
EMH08092 9.2 10 61 103
EMH08093 9.3 10 61 103
EMH08094 9.4 10 61 103
EMH08095 9.5 10 61 103
EMH08096 9.6 10 61 103
EMH08097 9.7 10 61 103
EMH08098 9.8 10 61 103
EMH08099 9.9 10 61 103
EMH08100 10.0 10 61 103
EMH08101 10.1 12 71 118
EMH08102 10.2 12 71 118
EMH08103 10.3 12 71 118
EMH08104 10.4 12 71 118
EMH08105 10.5 12 71 118
EMH08106 10.6 12 71 118
EMH08107 10.7 12 71 118
EMH08108 10.8 12 71 118
EMH08109 10.9 12 71 118
EMH08110 11.0 12 71 118
EMH08111 11.1 12 71 118
EMH08112 11.2 12 71 118
EMH08113 11.3 12 71 118
EMH08114 11.4 12 71 118
EMH08115 11.5 12 71 118
EMH08116 11.6 12 71 118
EMH08117 11.7 12 71 118
EMH08118 11.8 12 71 118
EMH08119 11.9 12 71 118
EMH08120 12.0 12 71 118
EMH08125 12.5 14 77 124
EMH08130 13.0 14 77 124
EMH08135 13.5 14 77 124
EMH08140 14.0 14 77 124
EMH08145 14.5 16 83 133
EMH08150 15.0 16 83 133
EMH08155 15.5 16 83 133
EMH08160 16.0 16 83 133
EMH08165 16.5 18 93 143
EMH08170 17.0 18 93 143
EMH08175 17.5 18 93 143
EMH08180 18.0 18 93 143
EMH08185 18.5 20 101 153
EMH08190 19.0 20 101 153
EMH08195 19.5 20 101 153
EMH08200 20.0 20 101 153

• Carbide drills with non-standard sizes or specifications not listed above can be customized according to customer needs.
