Die Cutting Creasing Machine
DieCutting Creasing Machine
The die cutting creasing machine is designed with multiple safetyprotection functions, so as to ensure safe and reliable performance. In addition, the machine also has thefunctions of single cut, time delay, continuous operation and sheet counting.Moreover, the brake clutch adopts electric disk type, ensuing sensitive brakingand safe performance. The template adopts adjustable frame, so it is easy to install and removeplates. Our die cutting creasing machine provides manual oil supply,centralized oil supply or CNC automatic oil supply. Also frequency control isavailable for the machine.
Technical Parameters of the Die CuttingCreasing Machine
| Type | Max. Effective Cutting Area | Working Speed | Length of Creasing Cutting Sheet | Motor Power | Net Weight | Overall Size （LxWxH ） |
| PYQ401C | 750x520mm | 28 ±2 (strokes/min) | ＜15m | 2.2kw | 2000kg | 1260x1350x1280mm |
| PYQ203D | 930x670mm | 23 ±2 (strokes/min) | ＜25m | 3.0kw | 3000kg | 1670x1670x1630mm |
| ML1100 | 1100x800mm | 20 ±2 (strokes/min) | ＜32m | 4.0kw | 4500kg | 1900x1780x1700mm |
| ML1200 | 1200x8300mm | 20 ±2 (strokes/min) | ＜35m | 4.0kw | 4800kg | 1920x2140x1920mm |
| ML1300 | 1300x920mm | 18 ±2 (strokes/min) | ＜40m | 5.5kw | 6000kg | 2000x2140x2000mm |
| ML1400 | 1400x1000mm | 17 ±2 (strokes/min) | ＜45m | 5.5kw | 6800kg | 2010x2400x1930mm |
| ML1500 | 1500x1050mm | 16 ±2 (strokes/min) | ＜45m | 5.5kw | 7500kg | 2010x2400x1930mm |
| ML1600 | 1600x1250mm | 16 ±2 (strokes/min) | ＜50m | 11kw | 11000kg | 2170x2560x2230mm |
| ML1800 | 1800x1300mm | 16 ±2 (strokes/min) | ＜62m | 15kw | 13500kg | 2240x2800x2130mm |
Note: The parameters above arejust for reference and are subject to change with the improvement of product.
