Automatic Shrink Sleeve Labeling Machine
Request a Quote
Sleeve labeler machine for applying heat-shrinkable sleeve labels on containers of complex shapes
- Versatile & Precise: Engineered for round, square, oval, and flat containers, this machine delivers high-speed application for full-body and neck labeling (tamper-evident) with a labeling precision of ±0.5mm. It offers full compatibility with PVC, PET, and OPS shrink films.
- Robust & Reliable: Constructed from premium 304/316 stainless steel, the unit is designed with water-proof, rust-proof durability in demanding environments. Powered by world-class servo motors and PLC, it achieves a stable output of 6,000-9,000 BPH.
- User-Friendly Design: With modular components for rapid changeovers, flexible label positioning, and an easy-to-use color touchscreen HMI, this solution maximizes uptime and production efficiency, making it the ultimate choice for modern automated packaging lines.
Parameters
| Model | |
| Input Power | 1.5KW |
| Input Voltage | 380/220VAC |
| Production Efficiency | 100-150 BPM |
| Dimension of Host Machine | L2100mm x W850mm x H2000mm |
| Applicable Diameter of Bottle Body | Φ28mm-Φ125mm |
| Applicable Length of Label | 30mm-250mm |
| Applicable Thickness of Label | 0.03mm-0.13mm |
| Applicable Inner Diameter of Paper Tube | 5"-10" (free adjustable) |
