Pipe diameter range: 89-127mm
Thread types: REMET, METZKE
Material: Low-carbon alloy steel

Typical Applications

RC drill pipes are suitable for a wide range of geological conditions, including complex formations and deep drilling operations. Typical applications include oil and gas exploration, geothermal energy exploration, groundwater investigation and water well drilling, geological sampling and resource exploration.

Water well drilling

Geological sampling

Technical Specifications

O.D., mm	Wall thickness, mm	Thread type	Wrench flats, mm	Flat width, mm	Flat location, mm		Inner tube to end, mm		Inner tube sealing face size, mm		Length, mm
O.D., mm	h	Thread type	d	K	L1	L2	L3	L4	D1	D2	L
89	6.5	REMET 3.5	79	50	130	46	35	9	Ø49.5	Ø49.5	6000
89	8.5	REMET 3.5	79	50	130	46	35	9	Ø49.5	Ø49.5	6000
102	6.5	REMET 4.0	91	50	104	30	35	7.5	Ø57.2	Ø57.2	6000
	6.5	METZKE 4.0	91	50	104	30	25.4	3.1	Ø54	Ø54	6000
	8.5	REMET 4.0	91	50	104	30	35	7.5	Ø57.2	Ø57.2	6000
	8.5	METZKE 4.0	91	50	104	30	25.4	3.1	Ø54	Ø54	6000
114	8.5	REMET 4.5	103	50	145	30	31.5	6.5	Ø63.5	Ø63.5	6000
114	8.5	METZKE 4.5	103	50	145	30	48.2	0	Ø57.2	Ø57.4	6000
127	8.5	REMET 4.5	116	50	145	30	31.5	6.5	Ø63.5	Ø63.5	6000
127	8.5	METZKE 4.5	116	50	145	30	48.2	0	Ø57.2	Ø57.4	6000

How is the drill pipe length selected?

Drill pipe length is typically selected based on drilling rig specifications. Common standard lengths include 1.5m, 3m, and 6m. Other lengths can be manufactured according to project requirements.

How should RC drill pipes be maintained?

Apply an appropriate amount of thread grease to the connections before each use.
Clean the drill pipes after operation to remove mud, cuttings, and debris.
Inspect pipes regularly and replace or repair damaged or deformed sections in time.
Store drill pipes in a dry, well-ventilated area, avoiding heavy loads and high humidity to prevent deformation and corrosion.
