CW-1000BSDS High Speed Bag Making Machine (Single/Double Line Side Seal and Bottom Seal Bag)

CW-1000BSDS High Speed Bag Making Machine (Single/Double Line Side Seal and Bottom Seal Bag)
Request a Quote

Brief Introduction
CW-1000BSDS high speed bag making machine is used for making single and double line printed bag. This bag maker has multi-functions on the basis of new design conception.

Features
1. Equipped with double servo drive and double photocell, our high speed bag making machine can be used for making single/double line side seal and bottom seal bag.
2. It can be applied to make big size single printed bag.
3. Heavy duty sealing knife system is adopted, which can turn over quickly, and it is easy for cleaning.
4. Fly knife cutter can easily change knife and operate.
5. Newly designed deceleration function when discharging bags, that is easy for collecting finished bags.

Optional Accessories
1. Single/double line heavy duty automatic unwinder
2. Single/double line hot stamping machine
3. Automatic collecting table
4. Double side sealing knife

Technical Parameters
Model CW-1000BSDS CW-1200BSDS
Bag type Bottom sealed bag Bottom sealed bag Side sealed bag Bottom sealed bag
Bag width 100-700mm 120-800mmx1 line 120-350mmx2 lines 100-700mm 150-1000mmx1 line 150-460mmx2 lines
Bag length 150-900mmx1 line 150-430mmx2 lines 150-1000mm 150-1100mmx1 line 150-520mmx2 lines 150-1000mm
Speed 60-180x1 line 120-360pcs total 2 lines 20-90x1 line 40-180pcs total 2 lines 60-160x1 line 120-320pcs total 2 lines 20-85x1 line 40-270pcs total 2 lines
Film thickness 0.012-0.15mm for one layer LDPE:0.03-0.4 (total) HDPE:0.025-0.22(total) 0.012-0.15mm for one layer LDPE:0.03-0.4 (total) HDPE:0.025-0.22(total)
Total power 15.5kw 16.3kw
Machine weight 1380kg 1580kg
Machine size 6210x1650x1610mm 6210x1850x1610mm
Air compressor 7.5HP 7.5HP
