Features of Pneumatic Four-color Pad Printer SPT-846SD
1. Four color printing with shuttle;
2. Easier operation for microprocessor controlling and digital display;
3. The pad printer equipped with an automatic 5-digit counter;
4. Machine Frame is made of aluminium alloy, so it is light and sturdy;
5. The ink roller is easy to be cleaned, fixed and dismounted;
6. The vertical stroke and the speed of the pad printer are both adjustable;
7. Adjustable working speed enable the machine to meet a wide range of requirements:
8. The machine can effectively prevent the ink drying;
9. Multi-color are available (from one-color to four-color) and the four ink cups can be adjusted independently for separate color registration;
10. An air jet is available for fast drying.

Parameters of Pneumatic Four-color Pad Printer SPT-846SD
Stroke distance 114.3 mm
Work stations 4
Plate size 100×250 mm
Ink cup size Φ90 mm
Max. pad pressure 1833 N(6bar)
Max. printing speed 800pcs/hr
Air consumption 353Litre/min(6bar)
Wattage 110/220v 60/50Hz 50w
Dimensions 1025×946×1405mm
Weight 170Kg
