Pneumatic 1-Color Pad Printer

Pneumatic 1-Color Pad Printer
Request a Quote

Features of Pneumatic One-color Pad Printer SPT-814D
1. Easier operation for the microprocessor controlling.
2. The Pad Printer equipped with a built-in five-digit auto counter.
3. Material: Aluminium alloy (making the pad printer has a solid structure and light weight);
4. Ink roller is easy to clean, install and uninstall;
5. It has independent pad up/down stroke and speed adjustment;
6. Auto balanced doctor blade available for efficient ink scraping;
7. Adjustable printing speed is available;
8. Suitable for thick ink film: The pad printer can ink twice for one time of printing;
9. The printing machine can effectively avoid ink drying at intervals;
10. Two color printing is also available;
11. Easy color registration for the printing machine equipped with an auto air blowing.

Parameters of Pneumatic One-color Pad Printer SPT-814D
Plate size 100×75,100,150mm
Max. pad pressure 1155N(6bar)
Max. printing speed 1400pcs/hr
Air consumption 159Litre/min(6bar)
Wattage 110/220v 60/50Hz 50w
Dimensions 861×460×1358mm
Weight 122HKg
