NNG1D-0/032F-20 DC-DC 5A Single Phase Solid State Relay

NNG1D-0/032F-20 DC-DC 5A Single Phase Solid State Relay
NNG1D-0/032F-20 DC-DC 5A Single Phase Solid State Relay
NNG1D-0/032F-20 DC-DC 5A Single Phase Solid State Relay
Request a Quote

The NNG1D-0/032F-20 DC-DC 5A single phase solid state relay is used in the automatic control filed like signal light, scintillator, stage lighting control system, instrument and apparatus, medical equipment, copier, automatic washing machine, automatic fire equipment and security system, and it also can be used as the selector switch of the power capacitor which be compensated by the network power factor. In addition, the NNG1D-0/032F-20 DC-DC 5A single phase solid state relay is widely used in the bad environment and frequent switching occasions like the chemical industry and coal industry which need prevent from explosion, damp, dust and erosion.

Model explanation
Specificationof NNG1D-0/032F-20 DC-DC 5A single phase solid state relay
Control voltage 032:3-32VDC
Control current 6-35mA
Connected voltage 3VDC
Turn off voltage 1VDC
Reverse voltage 32VDC
Load voltage 22:24-240VAC 38:40-440-VAC
06:12-60VDC 11:12-110VDC 20:12-200VDC
Load current 5A
Transient voltage 22:220VAC 38:900VAC
06:75VDC 11:150VDC 20:220VDC
On-state voltage drop AC:≤1.6VAC DC:≤1.2VDC
On-off time AC:≤10mS DC:≤5mS
Off-state leakage current AC:≤10mA DC:≤5mA
Dielectric withstand voltage ≥1500VAC
Insulation resistance Testing in 500MΩ,500VDC
Environmental temperature -30℃~80℃
Installation style Single inline package
Relay weight ≈30g
Dimension 43×12×34mm
Notice Please install the device nearby the heat dissipation window with good ventilation
Dimension and installation

① Dimension figure; ② Install size; ③ Wiring diagram; ④ Control power supply ⑤ Input ⑥ Ssr ⑦ Output ⑧ Load ⑨ Load power supply
