Triple Pass Dryer

Triple Pass Dryer
Request a Quote

Our triple pass dryer is characterized by compact structure, reasonable layout, reliable running, high thermal efficiency, and low power consumption.

Features
  • With self-insulated drums, the triple pass dryer has thermal efficiency as high as 80% while the thermal efficiency of single drum drying machine is only 35%. Compared with the single drum product, the triple drum drying machine saves coal by 68% and its output is increased by 100%.
  • The length of the triple drum rotary drying machine is only 40% of that of the single drum product, which is conducive to process layout. This also reduces plant construction area and saves 40% of the project investment. The floor area of this triple pass dryer is approximately 20 square meters.
  • Our product adopts the heat-resistant, wear-resistant alloy steel plate which is four time more wear-resistant than ordinary steel plate, so it has long service life.
  • Temperature of the material discharged from the triple pass dryer is lower than 60℃ while the discharging material from the single drum drying machine is 150℃ in temperature. The low outlet temperature helps to extend the service time of the dust removal equipment. An air box pulse bag type dust remover can be used.
  • The hot blast stove can be used in conjunction with the fluidized bed furnace, coal stove, and gas furnace.
Technical Parameters
Specification φ2.0×6m φ2.5×6.5m φ2.7×7m φ3×7m φ3.2×7m φ3.6×8m φ4.2×8.5m
Diameter of the outer drum
m
2.0 2.5 2.7 3 3.2 3.6 4.2
Length of the outer drum
m
6 6.5 7 7 7 8 8.5
Drum volume
m3
18.84 31.89 40.5 49.46 56.26 81.38 118
Drum speed
rpm
3-10 3-10 3-10 3-10 3-10 3-10 3-10
Residence time of material
min
12-30 12-30 12-30 12-30 12-30 12-30 12-30
Initial moisture content of material
%
6-25 6-25 6-25 6-25 6-25 6-25 6-25
Final moisture content of material
%
≤1 ≤1 ≤1 ≤1 ≤1 ≤1 ≤1
Maximum air intake temperature ℃ 750-900℃ 750-900℃ 750-900℃ 750-900℃ 750-900℃ 750-900℃ 750-900℃
Capacity
T/H
Slag 20-25 25-30 30-35 35-10 40-45 50-65 70-85
Fly ash 10-17 17-21 20-25 23-27 25-30 30-45 45-63
Yellow sand20-27 25-40 27-45 30-45 35-50 55-75 75-99
Motor modelYr160m-4 Yr132m-4E Yr160m-4 Yr160m-4 Yr132m-5E Yr160m-4E Yr160m-4E
Motor power
KW
7.5×2 11×2 7.5×4 7.5×4 11×4 15×4 18.5×4
Reducer model XWD-6 XWD-6 XWD-6 XWD-6 XWD-6 XWD-8 XWD-8
Reducer speed ratio 17-29 17-29 17-29 17-29 17-29 17-29 17-29
Equipment weight
T
25 32 35 38 43 57 77
