Rear Drive Axle Assembly HQ10D Series
Request a Quote
Your Motion
This product has been discontinued and removed from our shelves.
Technical Specifications
| Braking Mode | Disc Brake |
| Braking Diameter (mm) | 130/160 |
| Structure | Split Semi-floating |
| Adaptive Gearbox Model | JS10 |
| Gear Ratio | 7/1; 13/1; 26/1 |
| Rated Output Torque (N·m) | 140 |
| Max. Output Torque (N·m) | 210 |
| Adaptive Motor | TF102AH |
| Rated Voltage (V) | 24/36/48 |
| Rated Power (W) | 350/500/750/1000 |
| Rated Torque (N·m) | 1.2/1.7/2.3/3.2 |
| Rated Current (A) | 9.5/13.5/21/28 |
| No-load Current (A) | ≤2.5 / ≤3 / ≤3.5 / ≤4 |
| No-load Revolution (RPM) | 3350/3350/3250/3250 |
| Rated Revolution (RPM) | 2800/2800/3000/3000 |
| Max. Torque (N·m) | 6/8.5/13/18 |
| Max. Power (W) | 700/1000/1500/2000 |
| Rated Efficiency (%) | ≥75 |
| Working Cycle (min.) | S1 |
| Insulation Class | F |
| Protection Level | IP33 |
Dimensions
| Model No. | HQ10D | HQ10D | HQ10D |
| L1 Size (mm) | 580 | 780 | 880 |
| L2 Size (mm) | 340 | 535 | 560 |
Remark: The size of L1 and L2 can be customized per your special requirements.
