Water Cooled Temperature Control Unit Manufacturer

Water Cooled Temperature Control Unit

Request a Quote

View All: http://moldingmachinepart.com/5-3-water-cooled-temperature-control-unit.html

The overall water cooled temperature control unit
304 stainless steel multistage pump
316 stainless steel plate condenser and evaporator
316 stainless steel heating tube

Features

This industrial temperature control unit combines cooling and heating devices to control the water temperature within a range of 5℃~90℃.
The heating module with a solid-state relay is exceptionally durable and reliable.
A branded and reliable compressor with built-in safety protection devices features a low noise, high durability and energy efficiency.
Alco thermostatic expansion valves.
The condenser and evaporator are made of 316 stainless steel plate heat exchangers to increase the cooling efficiency by 30%.
An SUS304 stainless steel water tank, piping and pump have an excellent resistance to corrosion and pressure, an excellent durability and an outstanding stability.
The microprocessor-based control system will automatically control and monitor the machine operations with an excellent stability, high precision and low failure rate.
Alarms and protections for refrigerant over high or over low pressure, compressor motor overload, abnormal refrigeration, abnormal temperature of cooling medium, temperature probe disconnection, phase reversal or loss, and more.
Durable high-pressure and large-flow stainless steel magnetic pumps are used to offer a uniform molding temperature, increase piping cleanliness, and improve production stability.

Technical specifications

Model			YK-CWS-H-3	YK-CWS-H-5			YK-CWS-H-8			YK-CWS-H-10		YK-CWS-H-15
Temperature range			5-90℃
Medium			Water
Cooling capacity (KW)		10℃	7.5	12.6			20.5			26.5		41.5
		15℃	9	14.8			24			31		49
Compressor		Power（KW）	2.2	3.7			6			7.5		11.2
Heater power			6	9			9			12		12
Refrigerant			R22 R407C R410A
Evaporator	Type		316 stainless steel plate evaporator
Condenser			316 stainless steel plate condenser
Water tank capacity (L)			60				120					150
Medium process pump	Power（KW）		0.55			0.75			1.5			2.2
	Max. pressure（MPa）		0.36			0.37			0.39			0.5
	Max. flow（L/min）		50			90			150			200
Cooling water flow（L/min）			50		76			115			139		206
Weight（Kg）			245		265			345			370		490
Total power（KW）			8.75		13.5			16.5			21		25.4
Breaker capacity（A）			63(200V, 3P)		100(200V, 3P)			100(200V, 3P)			100(200V, 3P)		125(200V, 3P)
			25(380V, 3P)		32(380V, 3P)			40(380V, 3P)			63(380V, 3P)		63(380V, 3P)
Supply voltage			AC200V±10%/ 60Hz 3P AC380V±10% 50Hz 3P
Alarms			Refrigerant over high or over low pressure, compressor or process pump overload, abnormal refrigeration, abnormal temperature of coolant fluid, temperature probe disconnection, phase reversal or loss
Dimensions（W×D×Hmm）			11005401000				13006401150					13007001300

The cooling capacity is the value of the cooling water 7℃, inlet cooling water 30℃ and outlet cooling water 35℃. In addition to regular models, customized water-cooled temperature control units in a variety of different specifications can be provided according to your production needs.
