Belt Filter Press, XYSD Series
Mechanical treatment of sludge in the past was inefficient and left its water content as high as 80%. This poor dewatering process exacerbated environmental pollution, creating a serious danger to public health.
Xuyang environmental protection company has developed a unique high-pressure belt sludge deep dewatering system for sludge deep dewatering. This up-to-date system uses a chemical approach to alter the water composition of the sludge by taking advantage of the process of 'sludge activation wall-breaking technology high-pressure belt-type deep dewatering', converting the water inside the sludge into free water and releasing the intracellular water from the cell body. The system then utilizes a self-manufactured belt-type deep dewatering machine to mechanically dehydrate the sludge to the desired water content, thus providing a single-stop solution for sludge reduction, stabilization and safe disposal.
Advantages
- With automation, labor costs are significantly reduced.
- High efficient dewatering.
- The press runs efficiently and the water content of the sludge is lowered to 60%.
- Simple operation
- The low energy consumption and operational cost makes using resources from sludge more convenient, ultimately reducing the costs of follow-up treatment processes.
- The low water content of the sludge reduces the environmental effect.
| Model | Belt width (mm) | Processing capacity (t/h) (Primary sludge water content of 80%) | Dry sludge (DS) throughput (kg/h) |
| | 750 | 0.3～0.8 | 0.06～0.16 |
| | 1000 | 0.8～1.5 | 0.16～0.3 |
| | 1400 | 1.5～3.5 | 0.3～0.7 |
| | 1800 | 3.0～5.5 | 0.6～1.1 |
