Professional Amplifier

Request a Quote

View All: http://htdzpro.com/6-5-professional-amplifier.html

2-channel, parallel or bridged, mono operating modes for flexible application.
Independent limiters for each channel offer dependable protection against distortion.
Precise signal and clip LED indicators to monitor performance.
High-current toroidal transformer for absolute reliability and lowest noise emission.
Independent DC and thermal overheat protection one each channel automatically protects amplifier and speakers.
“Back-to front” ventilation system including air filler will automatically adjust fan speed for smooth operation.
Balanced XLR and 1/4” TRS inputs.
Professional connectors compatible to speakON and “touch –proof” binding post loudspeaker outputs enable secure operation.

Model No.		HT-P300	HT-P400	HT-P600
Input Power		AC 220V 50~60Hz	AC 220V 50~60Hz	AC 220V 50~60Hz
Input Sensitivity/ Impedance		500mv/20K Ohm	500mv/22K Ohm	500mv/20K Ohm
Output Consumption	8 Ohm	2×300W	2×400W	2×600W
	4 Ohm	2×500W	2×600W	2×800W
	Bridge 8 Ohm	800W	900W	1500W
Frequency Response		20Hz-20KHz	20Hz-20KHz	20Hz-20KHz
S/N ratio		>90dB	>90dB	>90dB
T.H.D.		< 0.05%	< 0.05%	< 0.05%
Channel Crosstalk		<-70dB	<-70dB	<-70dB
Channel Impedance		4~16 Ohm	4~16 Ohm	4~16 Ohm
N.W.		14.2kg	15.8kg	18.5kg

HT-P200/P350/P450/P650

MODEL NUMBER		HT-P200	HT-P350	HT-P450	HT-P650
Input sensitivity/impedance		500mv/20KΩ	500mv/22KΩ	500mv/20KΩ	500mv/22KΩ
Output consumption	8Ohm	2 X 200W	2 X 350W	2 X 450W	2 X 650W
	4Ohm	2 X 350W	2 X 550W	2 X 650W	2 X 850W
	Bridged 8Ohm	600W	850W	1050W	1550W
Frequency response		20Hz-20KHz	20Hz-20KHz	20Hz-20KHz	20Hz-20KHz
S/N ratio		>90dB	>90dB	>90dB	>90dB
T.H.D.		< 0.05%	< 0.05%	< 0.05%	< 0.05%
Channel Crosstalk		<-70dB	<-70dB	<-70dB	<-70dB
Output impedance		4~16Ω	4~16Ω	4~16Ω	4~16Ω
N.W.		12kg	13kg	16kg	19kg

HT-P200/P350/P450/P650

MODEL NUMBER	HT-M200	HT-M300	HT-M450	HT-M600	HT-M800	HT-M1000	HT-M1200	HT-M1500
Output Consumption 80	2x200W	2x300W	2x450W	2x600W	2x800W	2x1000W	2x1200W	2x1500\A
Output Consumption 4Q	2x300W	2x450W	2x675W	2x900W	2x1200W	2x1500W	2x1800W	2x2250V
Output Consumption 80 (Bridged)	600W	900W	1350W	1800W	2400W	3000W	3600W	4500W
Frequency Response	20Hz〜20kHz(±0.5%}
T.H.D (8Q/1 KHz)	< 0.5%(20Hz~20kHz)
Switching Rate	10V/MS
Damping coefficient(8Q/10~400Hz)	>200dB
Input Sensitivity	0.77V, 1.4Vf32dB
Input Impedance	UNBAL 10KΩ/BAL20KΩ
Voltage Gain (80/1 KHz)	33dB/36dB/39dB/41dB
Cormector	lnput:XLR(Mx2 Fx2); Output:SpeakON x2; PK-BFAx4
S/N Ratio	≥100 dB
Protection and cooling	Returned switch(ss);DC fault disconnect;Active inrush limiting;Short/Open circuit, RF overload and overheating protection
Dimension (mm)	483mmx88.9mmx482mm
N.W	10kg	10.5kg	11kg	12kg	14kg	16kg	18kg	20kg
