Automatic Copper Foil Assembly Machine

Automatic Copper Foil Assembly Machine
Request a Quote
View All: http://datacableequipment.com/7-1-automatic-copper-foil-assembly-machine.html

Our automatic copper foil assembly machine is mainly used for copper foil wrapping on twisted data cables.

Operation Process
  • Manual wire placing
  • Automatic copper foil wrapping
Technical Parameters
  • Power supply: 220V, 50HZ
  • Power: 800W
  • Air pressure: 0.6-0.8Mpa,
  • Production output: 800Pcs/H
