LHS150-24 Automatic Fine Wire Drawing Machine
Request a Quote
Descriptions
The LHS150-24 automatic fine wire drawing line’s finished wire diameter ranges between 0.03mm to 0.12mm, which satisfies most customer needs, making it one of our most popular pieces of equipment.
This equipment features a maximum of 24 wire drawing dies, and customers can choose between a diamond and carbide die to meet their needs. This wire drawing machine also utilizes an on-tension rod structure, with spooling work PLC controlled. This allows for simultaneous multi-device operation by a single operator, ensuring a better efficiency.
| Model | LHS150-24 |
| Inlet Wire Diameter | φ0.12-0.55mm |
| Finished Wire Diameter | φ0.030-φ0.12mm |
| Drawing speed max | 2200m/min |
| Number of Drawing Dies | 24 |
| Die elongation | 10% - 11% |
| Lubrication Method | Lubricant spraying (flat fan) |
| Total Power | 8.2kW |
| Motor Power | 4/4kW |
| line arrangement | Ball screw driven by servo motor to rotate take-up axis |
| Take-up Bobbin Diameter | φ200×216×φ160×180×φ80mm (Plastic bobbin 12kg) φ300×270×φ215×250×φ120mm(lron bobbin 50kg) |
| Machine Dimension | 1495×1340×1812mm(L×W×H) |
| Machine Weight | 1.27t |
| Max. Take-up Bobbin Weight | 12-50kg |
| Display | Touch screen |
